Copper

Copper is a chemical element with the symbol Cu (from Latin: cuprum) and atomic number 29. It is a ductile metal with very high thermal and electrical conductivity. Pure copper is soft and malleable; a freshly exposed surface has a reddish-orange color. It is used as a conductor of heat and electricity, a building material, and a constituent of various metal alloys.

The metal and its alloys have been used for thousands of years. In the Roman era, copper was principally mined on Cyprus, hence the origin of the name of the metal asсyprium (metal of Cyprus), later shortened to сuprum. Its compounds are commonly encountered as copper(II) salts, which often impart blue or green colors to minerals such as azurite and turquoise and have been widely used historically as pigments. Architectural structures built with copper corrode to give green verdigris (or patina).Decorative art prominently features copper, both by itself and as part of pigments.

Copper is essential to all living organisms as a trace dietary mineral because it is a key constituent of the respiratory enzyme complex cytochrome c oxidase. In molluscs andcrustacea copper is a constituent of the blood pigment hemocyanin, which is replaced by the iron-complexed hemoglobin in fish and other vertebrates. The main areas where copper is found in humans are liver, muscle and bone.[2] Copper compounds are used asbacteriostatic substances, fungicides, and wood preservatives.

Characteristics

A copper disc (99.95% pure) made by continuous casting and etching.

Copper just above its melting point keeps its pink luster color when enough light outshines the orangeincandescence color.

Copper, silver and gold are in group 11 of the periodic table, and they share certain attributes: they have one s-orbital electron on top of a filled d-electron shell and are characterized by high ductility and electrical conductivity. The filled d-shells in these elements do not contribute much to the interatomic interactions, which are dominated by the s-electrons through metallic bonds. Contrary to metals with incomplete d-shells, metallic bonds in copper are lacking a covalent character and are relatively weak. This explains the low hardness and high ductility of single crystals of copper.[3] At the macroscopic scale, introduction of extended defects to the crystal lattice, such as grain boundaries, hinders flow of the material under applied stress thereby increasing its hardness. For this reason, copper is usually supplied in a fine-grainedpolycrystalline form, which has greater strength thanmonocrystalline forms.[4]

The softness of copper partly explains its high electrical conductivity (59.6×106 S/m) and thus also high thermal conductivity, which are the second highest among pure metals at room temperature.[5] This is because the resistivity to electron transport in metals at room temperature mostly originates from scattering of electrons on thermal vibrations of the lattice, which are relatively weak for a soft metal.[3] The maximum permissible current density of copper in open air is approximately 3.1×106 A/m2 of cross-sectional area, above which it begins to heat excessively.[6] As with other metals, if copper is placed against another metal, galvanic corrosion will occur.[7]

Together with caesium and gold (both yellow), and osmium (bluish), copper is one of only four elemental metals with a natural color other than gray or silver.[8] Pure copper is orange-red and acquires a reddish tarnish when exposed to air. The characteristic color of copper results from the electronic transitions between the filled 3d and half-empty 4s atomic shells – the energy difference between these shells is such that it corresponds to orange light. The same mechanism accounts for the yellow color of gold and caesium.[3]
Chemical

Unoxidized copper wire (left) and oxidized copper wire (right).

The East Tower of the Royal Observatory, Edinburgh. The contrast between the refurbished copper installed in 2010 and the green color of the original 1894 copper is clearly seen.

Copper forms a rich variety of compounds with oxidation states +1 and +2, which are often called cuprous andcupric, respectively.[9] It does not react with water, but it slowly reacts with atmospheric oxygen forming a layer of brown-black copper oxide. In contrast to the oxidation of iron by wet air, this oxide layer stops the further, bulk corrosion. A green layer of verdigris (copper carbonate) can often be seen on old copper constructions, such as the Statue of Liberty, the largest copper statue in the world built using repoussé and chasing.[10] Copper tarnisheswhen exposed to hydrogen sulfides and other sulfides, which react with it to form various copper sulfides on the surface.[11] Oxygen-containing ammonia solutions give water-soluble complexes with copper, as do oxygen and hydrochloric acid to form copper chlorides and acidified hydrogen peroxide to form copper(II) salts. Copper(II) chloride and copper comproportionate to form copper(I) chloride.[12]
Isotopes
Main article: Isotopes of copper

There are 29 isotopes of copper. 63Cu and 65Cu are stable, with 63Cu comprising approximately 69% of naturally occurring copper; they both have a spin of 3/2.[13] The other isotopes are radioactive, with the most stable being 67Cu with a half-life of 61.83 hours.[13]Seven metastable isotopes have been characterized, with 68mCu the longest-lived with a half-life of 3.8 minutes. Isotopes with a mass number above 64 decay by β-, whereas those with a mass number below 64 decay by β+. 64Cu, which has a half-life of 12.7 hours, decays both ways.[14]

62Cu and 64Cu have significant applications. 64Cu is a radiocontrast agent for X-ray imaging, and complexed with a chelate can be used for treating cancer. 62Cu is used in 62Cu-PTSM that is a radioactive tracer for positron emission tomography.[15]
Occurrence

Native Copper from the Keweenaw Peninsula Michigan about 2.5 inches (6.4 cm) long

Copper is synthesized in massive stars[16] and is present in the Earth's crust at a concentration of about 50 parts per million (ppm),[17] where it occurs as native copper or in minerals such as the copper sulfideschalcopyrite and chalcocite, copper carbonates azurite and malachite and the copper(I) oxide mineralcuprite.[5] The largest mass of elemental copper discovered weighed 420 tonnes and was found in 1857 on the Keweenaw Peninsula in Michigan, US.[17] Native copper is a polycrystal, with the largest described single crystal measuring 4.4×3.2×3.2 cm.[18]
Production

Chuquicamata in Chile is one of the world's largest open pit copper mines.

World production trend

Copper output in 2005

Copper prices 2003–2011 in USD per tonne
See also: List of countries by copper production

Most copper is mined or extracted as copper sulfides from large open pit mines in porphyry copper deposits that contain 0.4 to 1.0% copper. Examples include Chuquicamata in Chile, Bingham Canyon Mine in Utah, United States and El Chino Mine in New Mexico, United States. According to theBritish Geological Survey, in 2005, Chile was the top mine producer of copper with at least one-third world share followed by the United States, Indonesia and Peru.[5] Copper can also be recovered through the In-situ leach process. Several sites in the state of Arizona are considered prime candidates for this method.[19]The amount of copper in use is increasing and the quantity available is barely sufficient to allow all countries to reach developed world levels of usage.[20]
Reserves

Copper has been in use at least 10,000 years, but more than 96% of all copper ever mined and smelted has been extracted since 1900, and more than half was extracted in only the last 24 years. As with many natural resources, the total amount of copper on Earth is vast (around 1014 tons just in the top kilometer of Earth's crust, or about 5 million years worth at the current rate of extraction). However, only a tiny fraction of these reserves is economically viable, given present-day prices and technologies. Various estimates of existing copper reserves available for mining vary from 25 years to 60 years, depending on core assumptions such as the growth rate.[21] Recycling is a major source of copper in the modern world.[22] Because of these and other factors, the future of copper production and supply is the subject of much debate, including the concept of Peak copper, analogous to Peak Oil.

The price of copper has historically been unstable,[23] and it quintupled from the 60-year low of US$0.60/lb (US$1.32/kg) in June 1999 to US$3.75 per pound (US$8.27/kg) in May 2006. It dropped to US$2.40/lb (US$5.29/kg) in February 2007, then rebounded to US$3.50/lb (US$7.71/kg) in April 2007.[24] In February 2009, weakening global demand and a steep fall in commodity prices since the previous year's highs left copper prices at US$1.51/lb.[25]
Methods
Main article: Copper extraction techniques

The concentration of copper in ores averages only 0.6%, and most commercial ores are sulfides, especially chalcopyrite (CuFeS2) and to a lesser extent chalcocite (Cu2S).[26] These minerals are concentrated from crushed ores to the level of 10–15% copper by froth flotation or bioleaching.[27] Heating this material with silica in flash smelting removes much of the iron as slag. The process exploits the greater ease of converting iron sulfides into its oxides, which in turn react with the silica to form the silicate slag, which floats on top of the heated mass. The resulting copper matte consisting of Cu2S is then roasted to convert all sulfides into oxides:[26]2 Cu2S + 3 O2 → 2 Cu2O + 2 SO2

The cuprous oxide is converted to blister copper upon heating:2 Cu2O → 4 Cu + O2

The Sudbury matte process converted only half the sulfide to oxide and then used this oxide to remove the rest of the sulfur as oxide. It was then electrolytically refined and the anode mud exploited for the platinum and gold it contained. This step exploits the relatively easy reduction of copper oxides to copper metal. Natural gas is blown across the blister to remove most of the remaining oxygen andelectrorefining is performed on the resulting material to produce pure copper:[28]Cu2+ + 2 e– → Cu
Recycling

Copper, like aluminium, is 100% recyclable without any loss of quality whether in a raw state or contained in a manufactured product. In volume, copper is the third most recycled metal after iron and aluminium. It is estimated that 80% of the copper ever mined is still in use today.[29] According to the International Resource Panel's Metal Stocks in Society report, the global per capita stock of Copper in use in society is 35–55 kg. Much of this is in more-developed countries (140–300 kg per capita) rather than less-developed countries (30–40 kg per capita).

The process of recycling copper follows roughly the same steps as is used to extract copper, but requires fewer steps. High purity scrap copper is melted in a furnace and then reduced and cast into billets and ingots; lower purity scrap is refined by electroplating in a bath of sulfuric acid.[30]
Alloys
See also: List of copper alloys

Numerous copper alloys exist, many with important uses. Brass is an alloy of copper and zinc. Bronze usually refers to copper-tinalloys, but can refer to any alloy of copper such as aluminium bronze. Copper is one of the most important constituents of carat silver and gold alloys and carat solders used in the jewelry industry, modifying the color, hardness and melting point of the resulting alloys.[31]

The alloy of copper and nickel, called cupronickel, is used in low-denomination coins, often for the outer cladding. The US 5-cent coin called nickel consists of 75% copper and 25% nickel and has a homogeneous composition. The 90% copper/10% nickel alloy is remarkable by its resistance to corrosion and is used in various parts being exposed to seawater. Alloys of copper with aluminium (about 7%) have a pleasant golden color and are used in decorations.[17] Some lead-free solders consist of tin alloyed with a small proportion of copper and other metals.[32]
Compounds

A sample of copper(I) oxide.
See also: Category:Copper compounds
Binary compounds

As for other elements, the simplest compounds of copper are binary compounds, i.e. those containing only two elements. The principal ones are the oxides, sulfides and halides. Bothcuprous and cupric oxides are known. Among the numerous copper sulfides, important examples include copper(I) sulfide and copper(II) sulfide.

The cuprous halides with chlorine, bromine, and iodine are known, as are the cupric halides with fluorine, chlorine, and bromine. Attempts to prepare copper(II) iodide give cuprous iodide and iodine.[9]2 Cu2+ + 4 I− → 2 CuI + I2
Coordination chemistry

Copper(II) gives a deep blue coloration in the presence of ammonia ligands. The one used here istetramminecopper(II) sulfate.

Copper, like all metals, forms coordination complexes with ligands. In aqueous solution, copper(II) exists as [Cu(H2O)6]2+. This complex exhibits the fastest water exchange rate (speed of water ligands attaching and detaching) for any transition metal aquo complex. Adding aqueoussodium hydroxide causes the precipitation of light blue solid copper(II) hydroxide. A simplified equation is:Cu2+ + 2 OH− → Cu(OH)2

Aqueous ammonia results in the same precipitate. Upon adding excess ammonia, the precipitate dissolves, forming tetraamminecopper(II):Cu(H2O)4(OH)2 + 4 NH3 → [Cu(H2O)2(NH3)4]2+ + 2 H2O + 2 OH−

Many other oxyanions form complexes; these include copper(II) acetate, copper(II) nitrate, andcopper(II) carbonate. Copper(II) sulfate forms a blue crystalline pentahydrate, which is the most familiar copper compound in the laboratory. It is used in a fungicide called the Bordeaux mixture.[33]

Ball-and-stick model of the complex [Cu(NH3)4(H2O)2]2+, illustrating theoctahedral coordination geometrycommon for copper(II).

Polyols, compounds containing more than one alcohol functional group, generally interact with cupric salts. For example, copper salts are used to test for reducing sugars. Specifically, usingBenedict's reagent and Fehling's solution the presence of the sugar is signaled by a color change from blue Cu(II) to reddish copper(I) oxide.[34] Schweizer's reagent and related complexes with ethylenediamine and other amines dissolve cellulose.[35] Amino acids form very stable chelate complexes with copper(II). Many wet-chemical tests for copper ions exist, one involving potassium ferrocyanide, which gives a brown precipitate with copper(II) salts.
Organocopper chemistry
Main article: Organocopper compound

Compounds that contain a carbon-copper bond are known as organocopper compounds. They are very reactive towards oxygen to form copper(I) oxide and have many uses in chemistry. They are synthesized by treating copper(I) compounds with Grignard reagents, terminal alkynes ororganolithium reagents;[36] in particular, the last reaction described produces a Gilman reagent. These can undergo substitution with alkyl halides to form coupling products; as such, they are important in the field of organic synthesis. Copper(I) acetylide is highly shock-sensitive but is an intermediate in reactions such as the Cadiot-Chodkiewicz coupling[37] and the Sonogashira coupling.[38] Conjugate addition toenones[39] and carbocupration of alkynes[40] can also be achieved with organocopper compounds. Copper(I) forms a variety of weak complexes with alkenes and carbon monoxide, especially in the presence of amine ligands.[41]
Copper(III) and copper(IV)

Copper(III) is most characteristically found in oxides. A simple example is potassium cuprate, KCuO2, a blue-black solid. The best studied copper(III) compounds are the cuprate superconductors. Yttrium barium copper oxide (YBa2Cu3O7) consists of both Cu(II) and Cu(III) centres. Like oxide, fluoride is a highly basic anion and is known to stabilize metal ions in high oxidation states. Indeed, both copper(III) and even copper(IV) fluorides are known, K3CuF6 and Cs2CuF6, respectively.[9]

Some copper proteins form oxo complexes, which also feature copper(III).[42] With di- and tripeptides, purple-colored copper(III) complexes are stabilized by the deprotonated amide ligands.[43]

Complexes of copper(III) are also observed as intermediates in reactions of organocopper compounds.
History
Copper Age
Main article: Copper Age

A corroded copper ingot from Zakros,Crete, shaped in the form of an animal skin typical in that era.

Copper occurs naturally as native copper and was known to some of the oldest civilizations on record. It has a history of use that is at least 10,000 years old, and estimates of its discovery place it at 9000 BC in the Middle East;[44] a copper pendant was found in northern Iraq that dates to 8700 BC.[45] There is evidence that gold and meteoric iron (but not iron smelting) were the only metals used by humans before copper.[46] The history of copper metallurgy is thought to have followed the following sequence: 1) cold working of native copper, 2) annealing, 3) smelting, and 4) the lost wax method. In southeastern Anatolia, all four of these metallurgical techniques appears more or less simultaneously at the beginning of the Neolithic c. 7500 BC.[47] However, just as agriculture was independently invented in several parts of the world (including Pakistan, China, and the Americas) copper smelting was invented locally in several different places. It was probably discovered independently in China before 2800 BC, in Central America perhaps around 600 AD, and in West Africa about the 9th or 10th century AD.[48] Investment casting was invented in 4500–4000 BC in Southeast Asia[44] and carbon dating has established mining at Alderley Edge in Cheshire, UK at 2280 to 1890 BC.[49] Ötzi the Iceman, a male dated from 3300–3200 BC, was found with an axe with a copper head 99.7% pure; high levels of arsenic in his hair suggest his involvement in copper smelting.[50] Experience with copper has assisted the development of other metals; in particular, copper smelting led to the discovery of iron smelting.[50] Production in the Old Copper Complex in Michigan and Wisconsin is dated between 6000 and 3000 BC.[51][52] Natural bronze, a type of copper made from ores rich in silicon, arsenic, and (rarely) tin, came into general use in the Balkans around 5500 BC. Previously the only tool made of copper had been the awl, used for punching holes in leather and gouging out peg-holes for wood joining. However, the introduction of a more robust form of copper led to the widespread use, and large-scale production of heavy metal tools, including axes,adzes, and axe-adzes.[citation needed]
Bronze Age
Main article: Bronze Age

Alloying copper with tin to make bronze was first practiced about 4000 years after the discovery of copper smelting, and about 2000 years after "natural bronze" had come into general use. Bronze artifacts from Sumerian cities and Egyptian artifacts of copper and bronze alloys date to 3000 BC.[53] The Bronze Age began in Southeastern Europe around 3700–3300 BC, in Northwestern Europe about 2500 BC. It ended with the beginning of the Iron Age, 2000–1000 BC in the Near East, 600 BC in Northern Europe. The transition between the Neolithic period and the Bronze Age was formerly termed the Chalcolithic period (copper-stone), with copper tools being used with stone tools. This term has gradually fallen out of favor because in some parts of the world the Calcholithic and Neolithic are coterminous at both ends. Brass, an alloy of copper and zinc, is of much more recent origin. It was known to the Greeks, but became a significant supplement to bronze during the Roman Empire.[53]
Antiquity and Middle Ages

In alchemy the symbol for copper was also the symbol for the goddess and planetVenus.

Chalcolithic copper mine in Timna Valley,Negev Desert, Israel.

In Greece, copper was known by the name chalkos (χαλκός). It was an important resource for the Romans, Greeks and other ancient peoples. In Roman times, it was known as aes Cyprium, aes being the generic Latin term for copper alloys and Cyprium from Cyprus, where much copper was mined. The phrase was simplified to cuprum, hence the English copper. Aphrodite and Venus represented copper in mythology and alchemy, because of its lustrous beauty, its ancient use in producing mirrors, and its association with Cyprus, which was sacred to the goddess. The seven heavenly bodies known to the ancients were associated with the seven metals known in antiquity, and Venus was assigned to copper.[54]

Britain's first use of brass occurred around the 3rd–2nd century BC. In North America, copper mining began with marginal workings by Native Americans. Native copper is known to have been extracted from sites on Isle Royale with primitive stone tools between 800 and 1600.[55] Copper metallurgy was flourishing in South America, particularly in Peru around 1000 AD; it proceeded at a much slower rate on other continents. Copper burial ornamentals from the 15th century have been uncovered, but the metal's commercial production did not start until the early 20th century.

The cultural role of copper has been important, particularly in currency. Romans in the 6th through 3rd centuries BC used copper lumps as money. At first, the copper itself was valued, but gradually the shape and look of the copper became more important. Julius Caesarhad his own coins made from brass, while Octavianus Augustus Caesar's coins were made from Cu-Pb-Sn alloys. With an estimated annual output of around 15,000 t, Roman copper mining and smelting activities reached a scale unsurpassed until the time of theIndustrial Revolution; the provinces most intensely mined were those of Hispania, Cyprus and in Central Europe.[56][57]

The gates of the Temple of Jerusalem used Corinthian bronze made by depletion gilding. It was most prevalent in Alexandria, where alchemy is thought to have begun.[58] In ancient India, copper was used in the holistic medical science Ayurveda for surgical instruments and other medical equipment. Ancient Egyptians (~2400 BC) used copper for sterilizing wounds and drinking water, and later on for headaches, burns, and itching. The Baghdad Battery, with copper cylinders soldered to lead, dates back to 248 BC to AD 226 and resembles a galvanic cell, leading people to believe this was the first battery; the claim has not been verified.[59]
Modern period

Acid mine drainage affecting the stream running from the disused Parys Mountaincopper mines

The Great Copper Mountain was a mine in Falun, Sweden, that operated from the 10th century to 1992. It produced two thirds of Europe's copper demand in the 17th century and helped fund many of Sweden's wars during that time.[60] It was referred to as the nation's treasury; Sweden had a copper backed currency.[61]

The uses of copper in art were not limited to currency: it was used by Renaissancesculptors, in photographic technology known as the daguerreotype, and the Statue of Liberty.Copper plating and copper sheathing for ships' hulls was widespread; the ships of Christopher Columbus were among the earliest to have this feature.[62] The Norddeutsche Affinerie in Hamburg was the first modern electroplating plant starting its production in 1876.[63] The German scientist Gottfried Osann invented powder metallurgy in 1830 while determining the metal's atomic mass; around then it was discovered that the amount and type of alloying element (e.g., tin) to copper would affect bell tones. Flash smelting was developed by Outokumpu in Finland and first applied at Harjavalta in 1949; the energy-efficient process accounts for 50% of the world’s primary copper production.[64]

The Intergovernmental Council of Copper Exporting Countries, formed in 1967 with Chile, Peru, Zaire and Zambia, played a similar role for copper as OPEC does for oil. It never achieved the same influence, particularly because the second-largest producer, the United States, was never a member; it was dissolved in 1988.[65]
Applications

Assorted copper fittings

The major applications of copper are in electrical wires (60%), roofing and plumbing (20%) and industrial machinery (15%). Copper is mostly used as a pure metal, but when a higher hardness is required it is combined with other elements to make an alloy (5% of total use) such as brass and bronze.[17] A small part of copper supply is used in production of compounds for nutritional supplements and fungicides in agriculture.[33][66] Machining of copper is possible, although it is usually necessary to use an alloy for intricate parts to get good machinability characteristics.
Wire and cable
Main article: Copper wire and cable

Despite competition from other materials, copper remains the preferred electrical conductorin nearly all categories of electrical wiring with the major exception being overhead electric power transmission where aluminium is often preferred.[67][68] Copper wire is used in power generation, power transmission, power distribution, telecommunications, electronicscircuitry, and countless types of electrical equipment.[69] Electrical wiring is the most important market for the copper industry.[70] This includes building wire, communications cable, power distribution cable, appliance wire, automotive wire and cable, and magnet wire. Roughly half of all copper mined is used to manufacture electrical wire and cable conductors.[71] Many electrical devices rely on copper wiring because of its multitude of inherent beneficial properties, such as its high electrical conductivity, tensile strength, ductility, creep (deformation) resistance, corrosion resistance, low thermal expansion, high thermal conductivity, solderability, and ease of installation.
Electronics and related devices

Copper electrical busbars distributing power to a large building

Integrated circuits and printed circuit boards increasingly feature copper in place of aluminium because of its superior electrical conductivity (see Copper interconnect for main article); heat sinks and heat exchangers use copper as a result of its superior heat dissipation capacity to aluminium. Electromagnets, vacuum tubes, cathode ray tubes, andmagnetrons in microwave ovens use copper, as do wave guides for microwave radiation.[72]
Electric motors
Main article: Copper in energy efficient motors

Copper’s greater conductivity versus other metallic materials enhances the electrical energy efficiency of motors.[73] This is important because motors and motor-driven systems account for 43%-46% of all global electricity consumption and 69% of all electricity used by industry.[74] Increasing the mass and cross section of copper in a coil increases the electrical energy efficiency of the motor. Copper motor rotors, a new technology designed for motor applications where energy savings are prime design objectives,[75][76] are enabling general-purpose induction motors to meet and exceed National Electrical Manufacturers Association (NEMA) premium efficiency standards.[77]
Architecture
Main article: Copper in architecture

Copper roof on the Minneapolis City Hall, coated with patina

Old copper utensils in a Jerusalem restaurant

Copper has been used since ancient times as a durable, corrosion resistant, and weatherproof architectural material.[78][79][80][81] Roofs, flashings, rain gutters, downspouts,domes, spires, vaults, and doors have been made from copper for hundreds or thousands of years. Copper’s architectural use has been expanded in modern times to include interior and exterior wall cladding, building expansion joints, radio frequency shielding, and antimicrobialindoor products, such as attractive handrails, bathroom fixtures, and counter tops. Some of copper’s other important benefits as an architectural material include its low thermal movement, light weight, lightning protection, and its recyclability.

The metal’s distinctive natural green patina has long been coveted by architects and designers. The final patina is a particularly durable layer that is highly resistant to atmospheric corrosion, thereby protecting the underlying metal against further weathering.[82][83][84] It can be a mixture of carbonate and sulfate compounds in various amounts, depending upon environmental conditions such as sulfur-containing acid rain.[85][86][87][88][89] Architectural copper and its alloys can also be 'finished' to embark a particular look, feel, and/or color. Finishes include mechanical surface treatments, chemical coloring, and coatings.[90]

Copper has excellent brazing and soldering properties and can be welded; the best results are obtained with gas metal arc welding.[91]
Antibiofouling applications
Main articles: Copper alloys in aquaculture and Copper sheathing

Copper has long been used as a biostatic surface to line parts of ships to protect againstbarnacles and mussels. It was originally used pure, but has since been superseded byMuntz metal. Bacteria will not grow on a copper surface because it is biostatic. Similarly, as discussed in copper alloys in aquaculture, copper alloys have become important netting materials in the aquaculture industry because of the fact that they are antimicrobial and prevent biofouling, even in extreme conditions[92] and have strong structural and corrosion-resistant[93] properties in marine environments.
Antimicrobial applications
Main articles: Antimicrobial properties of copper and Antimicrobial copper-alloy touch surfaces

Numerous antimicrobial efficacy studies have been conducted in the past 10 years regarding copper’s efficacy to destroy a wide range of bacteria, as well as influenza A virus, adenovirus, and fungi.[94]

Copper-alloy touch surfaces have natural intrinsic properties to destroy a wide range of microorganisms (e.g., E. coli O157:H7,methicillin-resistant Staphylococcus aureus (MRSA), Staphylococcus, Clostridium difficile, influenza A virus, adenovirus, and fungi).[94]Some 355 copper alloys were proven to kill more than 99.9% of disease-causing bacteria within just two hours when cleaned regularly.[95] The United States Environmental Protection Agency (EPA) has approved the registrations of these copper alloys as “antimicrobial materials with public health benefits,"[95] which allows manufacturers to legally make claims as to the positive public health benefits of products made with registered antimicrobial copper alloys. In addition, the EPA has approved a long list of antimicrobial copper products made from these alloys, such as bedrails, handrails, over-bed tables, sinks, faucets, door knobs, toilethardware, computer keyboards, health club equipment, shopping cart handles, etc. (for a comprehensive list of products, see:Antimicrobial copper-alloy touch surfaces#Approved products). Copper doorknobs are used by hospitals to reduce the transfer of disease, and Legionnaires' disease is suppressed by copper tubing in plumbing systems.[96] Antimicrobial copper alloy products are now being installed in healthcare facilities in the U.K., Ireland, Japan, Korea, France, Denmark, and Brazil and in the subway transit system in Santiago, Chile, where copper-zinc alloy handrails will be installed in some 30 stations between 2011–2014.[97][98][99]
Other uses

Copper compounds in liquid form are used as a wood preservative, particularly in treating original portion of structures during restoration of damage due to dry rot. Together with zinc, copper wires may be placed over non-conductive roofing materials to discourage the growth of moss. Textile fibers use copper to create antimicrobial protective fabrics,[100] as do ceramic glazes, stained glass and musical instruments. Electroplating commonly uses copper as a base for other metals such as nickel.

Copper is one of three metals, along with lead and silver, used in a museum materials testing procedure called the Oddy test. In this procedure, copper is used to detect chlorides, oxides, and sulfur compounds.

Copper is commonly used in jewelry, and folklore says that copper bracelets relieve arthritis symptoms.[101] Copper is the principal alloying metal in sterling silver and gold alloys. It may also be used on its own, or as a constituent of brass, bronze, gilding metal and many other base metal alloys.

Copper is used as the printing plate in etching, engraving and other forms of intaglio (printmaking) printmaking

Copper oxide and carbonate is used in glassmaking and in ceramic glazes to impart green and brown colors.
Biological role
Main article: Copper in health

Rich sources of copper include oysters, beef and lamb liver, Brazil nuts, blackstrap molasses, cocoa, and black pepper. Good sources include lobster, nuts and sunflower seeds, green olives, avocados, and wheat bran.

Copper proteins have diverse roles in biological electron transport and oxygen transportation, processes that exploit the easy interconversion of Cu(I) and Cu(II).[102] [103] [104] The biological role for copper commenced with the appearance of oxygen in earth's atmosphere.[105] The protein hemocyanin is the oxygen carrier in most mollusks and somearthropods such as the horseshoe crab (Limulus polyphemus).[106] Because hemocyanin is blue, these organisms have blue blood, not the red blood found in organisms that rely onhemoglobin for this purpose. Structurally related to hemocyanin are the laccases andtyrosinases. Instead of reversibly binding oxygen, these proteins hydroxylate substrates, illustrated by their role in the formation of lacquers.[104]

Copper is also a component of other proteins associated with the processing of oxygen. Incytochrome c oxidase, which is required for aerobic respiration, copper and iron cooperate in the reduction of oxygen. Copper is also found in many superoxide dismutases, proteins that catalyze the decomposition of superoxides, by converting it (by disproportionation) to oxygen and hydrogen peroxide:2 HO2 → H2O2 + O2

Several copper proteins, such as the "blue copper proteins", do not interact directly with substrates, hence they are not enzymes. These proteins relay electrons by the process called electron transfer.[104]

Photosynthesis functions by an elaborate electron transport chain within the thylakoid membrane. A central "link" in this chain is plastocyanin, a blue copper protein.
Dietary needs

Copper is an essential trace element in plants and animals, but not some microorganisms. The human body contains copper at a level of about 1.4 to 2.1 mg per kg of body mass.[107] Stated differently, the RDAfor copper in normal healthy adults is quoted as 0.97 mg/day and as 3.0 mg/day.[108] Copper is absorbed in the gut, then transported to the liver bound to albumin.[109] After processing in the liver, copper is distributed to other tissues in a second phase. Copper transport here involves the protein ceruloplasmin, which carries the majority of copper in blood. Ceruloplasmin also carries copper that is excreted in milk, and is particularly well-absorbed as a copper source.[110] Copper in the body normally undergoesenterohepatic circulation (about 5 mg a day, vs. about 1 mg per day absorbed in the diet and excreted from the body), and the body is able to excrete some excess copper, if needed, via bile, which carries some copper out of the liver that is not then reabsorbed by the intestine.[111][112]
Copper-based disorders

Because of its role in facilitating iron uptake, copper deficiency can produce anemia-like symptoms, neutropenia, bone abnormalities, hypopigmentation, impaired growth, increased incidence of infections, osteoporosis, hyperthyroidism, and abnormalities in glucose and cholesterol metabolism. Conversely, Wilson's disease causes an accumulation of copper in body tissues.

Severe deficiency can be found by testing for low plasma or serum copper levels, low ceruloplasmin, and low red blood cell superoxide dismutase levels; these are not sensitive to marginal copper status. The "cytochrome c oxidase activity of leucocytes and platelets" has been stated as another factor in deficiency, but the results have not been confirmed by replication.[113]

NFPA 704


0
2
0

Fire diamond for copper metal

Main article: Copper toxicity

Gram quantities of various copper salts have been taken in suicide attempts and produced acute copper toxicity in humans, possibly due to redox cycling and the generation of reactive oxygen species that damage DNA.[114]Corresponding amounts of copper salts (30 mg/kg) are toxic in animals.[115] A minimum dietary value for healthy growth in rabbits has been reported to be at least 3 ppm in the diet.[116] However, higher concentrations of copper (100 ppm, 200 ppm, or 500 ppm) in the diet of rabbits may favorably influence feed conversion efficiency, growth rates, and carcass dressing percentages.[117]

Chronic copper toxicity does not normally occur in humans because of transport systems that regulate absorption and excretion. Autosomal recessive mutations in copper transport proteins can disable these systems, leading toWilson's disease with copper accumulation and cirrhosis of the liver in persons who have inherited two defective genes.

Read More

Iron

Iron is a chemical element with the symbol Fe (from Latin: ferrum) and atomic number26. It is a metal in the first transition series. It is the most common element (by mass) forming the planet Earth as a whole, forming much of Earth's outer and inner core. It is the fourth most common element in the Earth's crust. Iron's very common presence inrocky planets like Earth is due to its abundant production as a result of fusion in high-mass stars, where the production of nickel-56 (which decays to the most common isotope of iron) is the last nuclear fusion reaction that is exothermic. This causes radioactive nickel to become the last element to be produced before collapse of asupernova leads to the explosive events that scatter this precursor radionuclide of iron abundantly into space.

Like other group 8 elements, iron exists in a wide range of oxidation states, −2 to +6, although +2 and +3 are the most common. Elemental iron occurs in meteoroids and other low oxygen environments, but is reactive to oxygen and water. Fresh iron surfaces appear lustrous silvery-gray, but oxidize in normal air to give hydrated iron oxides, commonly known as rust. Unlike many other metals which form passivating oxide layers, iron oxides occupy more volume than iron metal, and thus iron oxides flake off and expose fresh surfaces for corrosion.

Iron metal has been used since ancient times, though copper alloys, which have lower melting temperatures, were used first in history. Pure iron is soft (softer than aluminium), but is unobtainable by smelting. The material is significantly hardened and strengthened by impurities from the smelting process, such as carbon. A certain proportion of carbon (between 0.002% and 2.1%) produces steel, which may be up to 1000 times harder than pure iron. Crude iron metal is produced in blast furnaces, where ore is reduced by coke topig iron, which has a high carbon content. Further refinement with oxygen reduces the carbon content to the correct proportion to make steel. Steels and low carbon iron alloyswith other metals (alloy steels) are by far the most common metals in industrial use, due to their great range of desirable properties and the abundance of iron.

Iron chemical compounds, which include ferrous and ferric compounds, have many uses. Iron oxide mixed with aluminium powder can be ignited to create a thermite reaction, used in welding and purifying ores. It forms binary compounds with the halogens and thechalcogens. Among its organometallic compounds is ferrocene, the first sandwich compound discovered.

Iron plays an important role in biology, forming complexes with molecular oxygen inhemoglobin and myoglobin; these two compounds are common oxygen transport proteins in vertebrates. Iron is also the metal used at the active site of many important redoxenzymes dealing with cellular respiration and oxidation and reduction in plants and animals.




Characteristics



Characteristic values of tensile strength (TS) and Brinell hardness (BH) of different forms of iron.
MaterialTS
(MPa)BH
(Brinell)
Iron whiskers 11000
Ausformed (hardened)
steel 2930 850–1200
Martensitic steel 2070 600
Bainitic steel 1380 400
Pearlitic steel 1200 350
Cold-worked iron 690 200
Small-grain iron 340 100
Carbon-containing iron 140 40
Pure, single-crystal iron 10 3


The mechanical properties of iron and its alloys can be evaluated using a variety of tests, including the Brinell test, Rockwell test and the Vickers hardness test. The data on iron is so consistent that it is often used to calibrate measurements or to compare tests.[4][5] However, the mechanical properties of iron are significantly affected by the sample's purity: pure research-purpose single crystals of iron are actually softer than aluminium,[3] and the purest industrially produced iron (99.99%) has a hardness of 20–30 Brinell.[6]An increase in the carbon content of the iron will initially cause a significant corresponding increase in the iron's hardness and tensile strength. Maximum hardness of 65 Rc is achieved with a 0.6% carbon content, although this produces a metal with a low tensile strength.[7]
Phase diagram and allotropes
Main article: Allotropes of iron

Iron represents an example of allotropy in a metal. There are at least four allotropic forms of iron, known as α, γ, δ, and ε; at very high pressures, some controversial experimental evidence exists for a phase β stable at very high pressures and temperatures.[8]

Low-pressure phase diagram of pure iron

As molten iron cools down it crystallizes at 1538 °C into its δ allotrope, which has abody-centered cubic (bcc) crystal structure. As it cools further its crystal structure changes to face-centered cubic(fcc) at 1394 °C, when it is known as γ-iron, or austenite. At 912 °C the crystal structure again becomes bcc as α-iron, or ferrite, is formed, and at 770 °C (the Curie point, Tc) iron becomes magnetic. As the iron passes through the Curie temperature there is no change in crystalline structure, but there is a change in "domain structure", where each domain contains iron atoms with a particular electronic spin. In unmagnetized iron, all the electronic spins of the atoms within one domain are in the same direction; the neighboring domains point in various directions and thus cancel out. In magnetized iron, the electronic spins of all the domains are aligned, so that the magnetic effects of neighboring domains reinforce each other. Although each domain contains billions of atoms, they are very small, about 10 micrometres across.[9] At pressures above approximately 10 GPa and temperatures of a few hundred kelvin or less, α-iron changes into a hexagonal close-packed (hcp) structure, which is also known as ε-iron; the higher-temperature γ-phase also changes into ε-iron, but does so at higher pressure. The β-phase, if it exists, would appear at pressures of at least 50 GPa and temperatures of at least 1500 K; it has been thought to have an orthorhombic or a double hcp structure.[8]

Iron is of greatest importance when mixed with certain other metals and with carbon to form steels. There are many types of steels, all with different properties, and an understanding of the properties of the allotropes of iron is key to the manufacture of good quality steels.

α-iron, also known as ferrite, is the most stable form of iron at normal temperatures. It is a fairly soft metal that can dissolve only a small concentration of carbon (no more than 0.021% by mass at 910 °C).[10]

Above 912 °C and up to 1400 °C α-iron undergoes a phase transition from bcc to the fcc configuration of γ-iron, also called austenite. This is similarly soft and metallic but can dissolve considerably more carbon (as much as 2.04% by mass at 1146 °C). This form of iron is used in the type of stainless steel used for making cutlery, and hospital and food-service equipment.[9]

The high-pressure phases of iron are important as endmember models for the solid parts of planetary cores. The inner core of the Earthis generally assumed to consist essentially of an iron-nickel alloy with ε (or β) structure.

The melting point of iron is experimentally well defined for pressures up to approximately 50 GPa. For higher pressures, different studies placed the γ-ε-liquid triple point at pressures differing by tens of gigapascals and yielded differences of more than 1000 K for the melting point. Generally speaking, molecular dynamics computer simulations of iron melting and shock wave experiments suggest higher melting points and a much steeper slope of the melting curve than static experiments carried out in diamond anvil cells.[11]
Isotopes
Main article: Isotopes of iron

Naturally occurring iron consists of four stable isotopes: 5.845% of 54Fe, 91.754% of 56Fe, 2.119% of 57Fe and 0.282% of 58Fe. Of these stable isotopes, only 57Fe has a nuclear spin (−1/2). The nuclide 54Fe is predicted to undergo double beta decay, but this process had never been observed experimentally for these nuclei, and only the lower limit on the half-life was established: t1/2>3.1×1022years.

60Fe is an extinct radionuclide of long half-life (2.6 million years).[12] It is not found on Earth, but its ultimate decay product is the stable nuclide nickel-60.

Much of the past work on measuring the isotopic composition of Fe has focused on determining 60Fe variations due to processes accompanying nucleosynthesis (i.e., meteorite studies) and ore formation. In the last decade however, advances in mass spectrometrytechnology have allowed the detection and quantification of minute, naturally occurring variations in the ratios of the stable isotopes of iron. Much of this work has been driven by the Earth and planetary science communities, although applications to biological and industrial systems are beginning to emerge.[13]

The most abundant iron isotope 56Fe is of particular interest to nuclear scientists as it represents the most common endpoint of nucleosynthesis. It is often cited, falsely, as the isotope of highest binding energy, a distinction which actually belongs to nickel-62.[14]Since 56Ni is easily produced from lighter nuclei in the alpha process in nuclear reactions in supernovae (see silicon burning process), nickel-56 (14 alpha particles) is the endpoint of fusion chains inside extremely massive stars, since addition of another alpha particle would result in zinc-60, which requires a great deal more energy. This nickel-56, which has a half-life of about 6 days, is therefore made in quantity in these stars, but soon decays by two successive positron emissions within supernova decay products in the supernova remnant gas cloud, first to radioactive cobalt-56, and then stable iron-56. This last nuclide is therefore common in the universe, relative to other stable metals of approximately the same atomic weight.

In phases of the meteorites Semarkona and Chervony Kut a correlation between the concentration of 60Ni, the daughter product of 60Fe, and the abundance of the stable iron isotopes could be found which is evidence for the existence of 60Fe at the time of formation of the Solar System. Possibly the energy released by the decay of 60Fe contributed, together with the energy released by decay of the radionuclide 26Al, to the remelting and differentiation of asteroids after their formation 4.6 billion years ago. The abundance of 60Ni present in extraterrestrial material may also provide further insight into the origin of the Solar System and its early history.[15]

Nuclei of iron atoms have some of the highest binding energies per nucleon, surpassed only by the nickel isotope 62Ni. This is formed by nuclear fusion in stars. Although a further tiny energy gain could be extracted by synthesizing 62Ni, conditions in stars are unsuitable for this process to be favored. Elemental distribution on Earth greatly favors iron over nickel, and also presumably in supernova element production.[16]

Iron-56 is the heaviest stable isotope produced by the alpha process in stellar nucleosynthesis; elements heavier than iron and nickel require a supernova for their formation. Iron is the most abundant element in the core of red giants, and is the most abundant metal iniron meteorites and in the dense metal cores of planets such as Earth.
Nucleosynthesis

Iron is created by extremely large, extremely hot (over 2.5 billion kelvin) stars through the silicon burning process. It is the heaviest stable element to be produced in this manner. The process starts with the second largest stable nucleus created by silicon burning, which is calcium. One stable nucleus of calcium fuses with one helium nucleus, creating unstable titanium. Before the titanium decays, it can fuse with another helium nucleus, creating unstable chromium. Before the chromium decays, it can fuse with another helium nucleus, creating unstable iron. Before the iron decays, it can fuse with another helium nucleus, creating unstable nickel-56. Any further fusion of nickel-56 consumes energy instead of producing energy, so after the production of nickel-56, the star does not produce the energy necessary to keep the core from collapsing. Eventually, the nickel-56 decays to unstable cobalt-56, which in turn decays to stable iron-56. When the core of the star collapses, it creates a supernova. Supernovas also create additional forms of stable iron via ther-process.
Occurrence
See also category: Iron minerals
Planetary occurrence

Iron meteorites of similar composition of Earth's inner and outer core

Iron is the sixth most abundant element in the Universe, and the most common refractoryelement.[17] It is formed as the final exothermic stage of stellar nucleosynthesis, by silicon fusion in massive stars.

Metallic or native iron is rarely found on the surface of the Earth because it tends to oxidize, but its oxides are pervasive and represent the primary ores. While it makes up about 5% of the Earth's crust, both the Earth's inner and outer core are believed to consist largely of an iron-nickel alloy constituting 35% of the mass of the Earth as a whole. Iron is consequently the most abundant element on Earth, but only the fourth most abundant element in the Earth's crust.[18][19] Most of the iron in the crust is found combined with oxygen as iron oxideminerals such as hematite and magnetite. Large deposits of iron are found in banded iron formations. These geological formations are a type of rock consisting of repeated thin layers of iron oxides, either magnetite (Fe3O4) or hematite (Fe2O3), alternating with bands of iron-poor shale and chert. The banded iron formations were laid down in the time between 3,700 million years ago and1,800 million years ago[20][21]

About 1 in 20 meteorites consist of the unique iron-nickel minerals taenite (35–80% iron) and kamacite (90–95% iron). Although rare,iron meteorites are the main form of natural metallic iron on the Earth's surface.[22] It was proven by Mössbauer spectroscopy that the red color of the surface of Mars is derived from an iron oxide-rich regolith.[23]
Stocks in use in society

According to the International Resource Panel's Metal Stocks in Society report, the global per capita stock of iron in use in society is 2200 kg. Much of this is in more-developed countries (7000–14000 kg per capita) rather than less-developed countries (2000 kg per capita).
Chemistry and compounds
See also category: Iron compounds
Oxidation
stateRepresentative compound
−2 Disodium tetracarbonylferrate (Collman's reagent)
−1
0 Iron pentacarbonyl
1 Cyclopentadienyliron dicarbonyl dimer ("Fp2")
2 Ferrous sulfate, ferrocene
3 Ferric chloride, ferrocenium tetrafluoroborate
4 Barium ferrate(IV)
5
6 Potassium ferrate


Iron forms compounds mainly in the +2 and +3 oxidation states. Traditionally, iron(II) compounds are called ferrous, and iron(III) compounds ferric. Iron also occurs in higher oxidation states, an example being the purple potassium ferrate (K2FeO4) which contains iron in its +6 oxidation state. Iron(IV) is a common intermediate in many biochemical oxidation reactions.[24][25] Numerous organometalliccompounds contain formal oxidation states of +1, 0, −1, or even −2. The oxidation states and other bonding properties are often assessed using the technique of Mössbauer spectroscopy.[26] There are also many mixed valence compounds that contain both iron(II) and iron(III) centers, such as magnetite and Prussian blue (Fe4(Fe[CN]6)3).[25] The latter is used as the traditional "blue" in blueprints.[27]

Hydrated iron(III) chloride, also known as ferric chloride

The iron compounds produced on the largest scale in industry areiron(II) sulfate (FeSO4·7H2O) and iron(III) chloride (FeCl3). The former is one of the most readily available sources of iron(II), but is less stable to aerial oxidation thanMohr's salt ((NH4)2Fe(SO4)2·6H2O). Iron(II) compounds tend to be oxidized to iron(III) compounds in the air.[25]

Unlike many other metals, iron does not form amalgams with mercury. As a result, mercury is traded in standardized 76 pound flasks (34 kg) made of iron.[28]
Binary compounds

Iron reacts with oxygen in the air to form various oxide and hydroxide compounds; the most common are iron(II,III) oxide (Fe3O4), and iron(III) oxide (Fe2O3). Iron(II) oxide also exists, though it is unstable at room temperature. These oxides are the principal ores for the production of iron (see bloomery and blast furnace). They are also used in the production offerrites, useful magnetic storage media in computers, and pigments. The best known sulfide is iron pyrite (FeS2), also known as fool's gold owing to its golden luster.[25]

The binary ferrous and ferric halides are well known, with the exception of ferric iodide. The ferrous halides typically arise from treating iron metal with the corresponding binary halogen acid to give the corresponding hydrated salts.[25]Fe + 2 HX → FeX2 + H2

Iron reacts with fluorine, chlorine, and bromine to give the corresponding ferric halides, ferric chloride being the most common:2 Fe + 3 X2 → 2 FeX3 (X = F, Cl, Br)
Coordination and organometallic compounds
See also: organoiron chemistry

Prussian blue

Several cyanide complexes are known. The most famous example is Prussian blue, (Fe4(Fe[CN]6)3). Potassium ferricyanide and potassium ferrocyanide are also known; the formation of Prussian blue upon reaction with iron(II) and iron(III) respectively forms the basis of a "wet" chemical test.[25] Prussian blue is also used as an antidote for thallium and radioactive caesium poisoning.[29][30] Prussian blue can be used in laundry bluing to correct the yellowish tint left by ferrous salts in water.

Ferrocene

Several carbonyl compounds of iron are known. The premier iron(0) compound is iron pentacarbonyl, Fe(CO)5, which is used to produce carbonyl iron powder, a highly reactive form of metallic iron. Thermolysis of iron pentacarbonyl gives the trinuclear cluster, triiron dodecacarbonyl. Collman's reagent, disodium tetracarbonylferrate, is a useful reagent for organic chemistry; it contains iron in the −2 oxidation state.Cyclopentadienyliron dicarbonyl dimer contains iron in the rare +1 oxidation state.[31]

Ferrocene is an extremely stable complex. The first sandwich compound, it contains an iron(II) center with twocyclopentadienyl ligands bonded through all ten carbon atoms. This arrangement was a shocking novelty when it was first discovered,[32] but the discovery of ferrocene has led to a new branch of organometallic chemistry. Ferrocene itself can be used as the backbone of a ligand, e.g. dppf. Ferrocene can itself be oxidized to theferrocenium cation (Fc+); the ferrocene/ferrocenium couple is often used as a reference in electrochemistry.[33]
History
Main article: History of ferrous metallurgy
Wrought iron

The symbol for Mars has been used since antiquity to represent iron.

The Delhi iron pillar is an example of the iron extraction and processing methodologies of India. The iron pillar at Delhi has withstood corrosion for the last 1600 years.

Iron objects of great age are much rarer than objects made of gold or silver due to the ease of corrosion of iron.[34] Beads made of meteoriciron in 3500 BC or earlier were found in Gerzah, Egypt by G. A. Wainwright.[35] The beads contain 7.5% nickel, which is a signature of meteoric origin since iron found in the Earth's crust has very little to no nickel content. Meteoric iron was highly regarded due to its origin in the heavens and was often used to forge weapons and tools or whole specimens placed in churches.[35] Items that were likely made of iron by Egyptians date from 2500 to 3000 BC.[34] Iron had a distinct advantage over bronze in warfare implements. It was much harder and more durable than bronze, although susceptible to rust. However, this is contested. Hittitologist Trevor Bryce argues that before advanced iron-working techniques were developed in India, meteoritic iron weapons used by early Mesopotamian armies had a tendency to shatter in combat, due to their high carbon content.[36]

The first iron production started in the Middle Bronze Age but it took several centuries before iron displaced bronze. Samples of smelted iron from Asmar, Mesopotamia and Tall Chagar Bazaar in northern Syria were made sometime between 2700 and 3000 BC.[37] The Hittitesappear to be the first to understand the production of iron from its ores and regard it highly in their society. They began to smelt iron between 1500 and 1200 BC and the practice spread to the rest of the Near East after their empire fell in 1180 BC.[37] The subsequent period is called the Iron Age. Iron smelting, and thus the Iron Age, reached Europe two hundred years later and arrived in Zimbabwe, Africa by the 8th century.[37] In China, iron only appears circa 700–500 BC.[38] Iron smelting may have been introduced into China through Central Asia.[39] The earliest evidence of the use of a blast furnace in China dates to the 1st century AD,[40] and cupola furnaces were used as early as early as the Warring States period (403–221 BC).[41] Usage of the blast and cupola furnace remained widespread during the Song and Tang Dynasties.[42]

Artifacts from smelted iron occur in India from 1800 to 1200 BC,[43] and in the Levant from about 1500 BC (suggesting smelting inAnatolia or the Caucasus).[44][45]

The Book of Genesis, fourth chapter, verse 22 contains the first mention of iron in the Old Testament of the Bible; "Tubal-cain, an instructor of every artificer in brass and iron."[34] Other verses allude to iron mining (Job 28:2), iron used as a stylus (Job 19:24), furnace (Deuteronomy 4:20), chariots (Joshua 17:16), nails (I Chron. 22:3), saws and axes (II Sam. 12:31), and cooking utensils (Ezekiel 4:3).[46] The metal is also mentioned in the New Testament, for example in Acts chapter 12 verse 10, "[Peter passed through] the iron gate that leadeth unto the city" of Antioch.[47]

Iron working was introduced to Greece in the late 11th century BC.[48] The spread of ironworking in Central and Western Europe is associated with Celtic expansion. According to Pliny the Elder, iron use was common in the Roman era.[35] The annual iron output of the Roman Empire is estimated at 84,750 t,[49] while the similarly populous Han China produced around 5,000 t.[50]

During the Industrial Revolution in Britain, Henry Cort began refining iron from pig iron to wrought iron (or bar iron) using innovative production systems. In 1783 he patented the puddling process for refining iron ore. It was later improved by others including Joseph Hall.
Cast iron

Cast iron was first produced in China during 5th century BC,[51] but was hardly in Europe until the medieval period.[52][53] The earliestcast iron artifacts were discovered by archaeologists in what is now modern Luhe County, Jiangsu in China. Cast iron was used inancient China for warfare, agriculture, and architecture.[54] During the medieval period, means were found in Europe of producing wrought iron from cast iron (in this context known as pig iron) using finery forges. For all these processes, charcoal was required as fuel.

Coalbrookdale by Night, 1801. Blast furnaces light the iron making town ofCoalbrookdale.

Medieval blast furnaces were about 10 feet (3.0 m) tall and made of fireproof brick; forced air was usually provided by hand-operated bellows.[53] Modern blast furnaces have grown much bigger.

In 1709, Abraham Darby I established a coke-fired blast furnace to produce cast iron. The ensuing availability of inexpensive iron was one of the factors leading to the Industrial Revolution. Toward the end of the 18th century, cast iron began to replace wrought iron for certain purposes, because it was cheaper. Carbon content in iron wasn't implicated as the reason for the differences in properties of wrought iron, cast iron and steel until the 18th century.[37]

Since iron was becoming cheaper and more plentiful, it also became a major structural material following the building of the innovative first iron bridge in 1778.
Steel
See also: Steelmaking

Steel (with smaller carbon content than pig iron but more than wrought iron) was first produced in antiquity by using a bloomery. Blacksmiths in Luristan in western Iran were making good steel by 1000 BC.[37] Then improved versions, Wootz steel by India andDamascus steel by China were developed around 300 BC and 500 AD respectively. These methods were specialized, and so steel did not become a major commodity until the 1850s.[55]

New methods of producing it by carburizing bars of iron in the cementation process were devised in the 17th century AD. In theIndustrial Revolution, new methods of producing bar iron without charcoal were devised and these were later applied to produce steel. In the late 1850s, Henry Bessemer invented a new steelmaking process, involving blowing air through molten pig iron, to produce mild steel. This made steel much more economical, thereby leading to wrought iron no longer being produced.[56]
Foundations of modern chemistry

Antoine Lavoisier used the reaction of water steam with metallic iron inside an incandescent iron tube to produce hydrogen in his experiments leading to the demonstration of the mass conservation. Anaerobic oxidation of iron at high temperature can be schematically represented by the following reactions:Fe + H2O → FeO + H22 Fe + 3 H2O → Fe2O3 + 3 H23 Fe + 4 H2O → Fe3O4 + 4 H2



Industrial production
See also: Iron ore

The production of iron or steel is a process containing two main stages, unless the desired product is cast iron. The first stage is to produce pig iron in a blast furnace. Alternatively, it may be directly reduced. The second is to make wrought iron or steel from pig iron by a further process.

The fining process of smelting iron ore to make wrought iron from pig iron, with the right illustration displaying men working a blast furnace, from the Tiangong Kaiwuencyclopedia, published in 1637 by Song Yingxing.

How iron was extracted in the 19th century

For a few limited purposes like electromagnet cores, pure iron is produced by electrolysis of a ferrous sulfate solution
Blast furnace
Main article: Blast furnace

Ninety percent of all mining of metallic ores is for the extraction of iron[citation needed]. Industrially, iron production involves iron ores, principally hematite (nominally Fe2O3) andmagnetite (Fe3O4) in a carbothermic reaction (reduction with carbon) in a blast furnace at temperatures of about 2000 °C. In a blast furnace, iron ore, carbon in the form of coke, and aflux such as limestone (which is used to remove silicon dioxide impurities in the ore which would otherwise clog the furnace with solid material) are fed into the top of the furnace, while a massive blast of heated air, about 4 tons per ton of iron,[53] is forced into the furnace at the bottom.

In the furnace, the coke reacts with oxygen in the air blast to produce carbon monoxide:2 C + O2 → 2 CO

The carbon monoxide reduces the iron ore (in the chemical equation below, hematite) to molten iron, becoming carbon dioxide in the process:Fe2O3 + 3 CO → 2 Fe + 3 CO2

Some iron in the high-temperature lower region of the furnace reacts directly with the coke:2 Fe2O3 + 3 C → 4 Fe + 3 CO2

The flux is present to melt impurities in the ore, principally silicon dioxide sand and othersilicates. Common fluxes include limestone (principally calcium carbonate) and dolomite(calcium-magnesium carbonate). Other fluxes may be used depending on the impurities that need to be removed from the ore. In the heat of the furnace the limestone flux decomposes tocalcium oxide (also known as quicklime):CaCO3 → CaO + CO2

Then calcium oxide combines with silicon dioxide to form a liquid slag.CaO + SiO2 → CaSiO3

The slag melts in the heat of the furnace. In the bottom of the furnace, the molten slag floats on top of the denser molten iron, and apertures in the side of the furnace are opened to run off the iron and the slag separately. The iron, once cooled, is called pig iron, while the slag can be used as a material in road construction or to improve mineral-poor soils for agriculture[53]

This heap of iron ore pellets will be used in steel production.
Direct iron reduction

Since coke is becoming more regulated due to environmental concerns, alternative methods of processing iron have been developed. "Direct iron reduction"[53] reduces iron ore to a powder called "sponge" iron or "direct" iron that is suitable for steelmaking. There are two main reactions that go on in the direct reduction process:

Natural gas is partially oxidized (with heat and a catalyst):2 CH4 + O2 → 2 CO + 4 H2

These gases are then treated with iron ore in a furnace, producing solid sponge iron:Fe2O3 + CO + 2 H2 → 2 Fe + CO2 + 2 H2O

Silica is removed by adding a limestone flux, later.
Further processes
Main articles: Steelmaking and Ironworks

Iron-carbon phase diagram, various stable solid solution forms

Pig iron is not pure iron, but has 4–5% carbon dissolved in it with small amounts of other impurities like sulfur, magnesium, phosphorus and manganese. As the carbon is the major impurity, the iron (pig iron) becomes brittle and hard. This form of iron, also known as cast iron, is used to cast articles in foundries such as stoves, pipes, radiators, lamp-posts and rails.

Alternatively pig iron may be made into steel (with up to about 2% carbon) or wrought iron (commercially pure iron). Various processes have been used for this, including finery forges, puddling furnaces,Bessemer converters, open hearth furnaces, basic oxygen furnaces, and electric arc furnaces. In all cases, the objective is to oxidize some or all of the carbon, together with other impurities. On the other hand, other metals may be added to make alloy steels.

The hardness of the steel depends upon its carbon content: the higher the percentage of carbon, the greater the hardness and the lesser the malleability. The properties of the steel can also be changed by several methods.

Annealing involves the heating of a piece of steel to 700–800 °C for several hours and then gradual cooling. It makes the steel softer and more workable.

Steel may be hardened by cold working. The metal is bent or hammered into its final shape at a relatively cool temperature. Cold forging is the stamping of a piece of steel into shape by a heavy press. Wrenches are commonly made by cold forging. Cold rolling, which involves making a thinner but harder sheet, and cold drawing, which makes a thinner but stronger wire, are two other methods of cold working. To harden the steel, it is heated to red-hot and then cooled by quenching it in the water. It becomes harder and more brittle. If it is too hardened, it is then heated to a required temperature and allowed to cool. The steel thus formed is less brittle.

Heat treatment is another way to harden steel. The steel is heated red-hot, then cooled quickly. The iron carbide molecules are decomposed by the heat, but do not have time to reform. Since the free carbon atoms are stuck, it makes the steel much harder and stronger than before.[53]

Sometimes both toughness and hardness are desired. A process called case hardening may be used. Steel is heated to about 900 °C then plunged into oil or water. Carbon from the oil can diffuse into the steel, making the surface very hard. The surface cools quickly, but the inside cools slowly, making an extremely hard surface and a durable, resistant inner layer.

Iron may be passivated by dipping it into a concentrated nitric acid solution. This forms a protective layer of oxide on the metal, protecting it from further corrosion.[57]
Applications
Metallurgical
Iron production 2009 (million tonnes)[58]CountryIron orePig ironDirect ironSteel
China 1,114.9 549.4 573.6
Australia 393.9 4.4 5.2
Brazil 305.0 25.1 0.011 26.5
Japan 66.9 87.5
India 257.4 38.2 23.4 63.5
Russia 92.1 43.9 4.7 60.0
Ukraine 65.8 25.7 29.9
South Korea 0.1 27.3 48.6
Germany 0.4 20.1 0.38 32.7
World1,594.9914.064.51,232.4


Iron is the most widely used of all the metals, accounting for 95% of worldwide metal production.[citation needed] Its low cost and high strength make it indispensable in engineering applications such as the construction of machinery and machine tools, automobiles, the hulls of large ships, and structural components for buildings. Since pure iron is quite soft, it is most commonly combined with alloying elements to make steel.

Commercially available iron is classified based on purity and the abundance of additives. Pig iron has 3.5–4.5% carbon[59] and contains varying amounts of contaminants such as sulfur, silicon and phosphorus. Pig iron is not a saleable product, but rather an intermediate step in the production of cast iron and steel. The reduction of contaminants in pig iron that negatively affect material properties, such as sulfur and phosphorus, yields cast iron containing 2–4% carbon, 1–6% silicon, and small amounts of manganese. It has a melting pointin the range of 1420–1470 K, which is lower than either of its two main components, and makes it the first product to be melted when carbon and iron are heated together. Its mechanical properties vary greatly and depend on the form the carbon takes in the alloy.

"White" cast irons contain their carbon in the form of cementite, or iron-carbide. This hard, brittle compound dominates the mechanical properties of white cast irons, rendering them hard, but unresistant to shock. The broken surface of a white cast iron is full of fine facets of the broken iron-carbide, a very pale, silvery, shiny material, hence the appellation.

In gray iron the carbon exists as separate, fine flakes of graphite, and also renders the material brittle due to the sharp edged flakes of graphite that produce stress concentration sites within the material. A newer variant of gray iron, referred to as ductile iron is specially treated with trace amounts of magnesium to alter the shape of graphite to spheroids, or nodules, reducing the stress concentrations and vastly increasing the toughness and strength of the material.

Wrought iron contains less than 0.25% carbon but large amounts of slag that give it a fibrous characteristic.[59] It is a tough, malleable product, but not as fusible as pig iron. If honed to an edge, it loses it quickly. Wrought iron is characterized by the presence of fine fibers of slag entrapped within the metal. Wrought iron is more corrosion resistant than steel. It has been almost completely replaced bymild steel for traditional "wrought iron" products and blacksmithing.

Mild steel corrodes more readily than wrought iron, but is cheaper and more widely available. Carbon steel contains 2.0% carbon or less,[60] with small amounts of manganese, sulfur, phosphorus, and silicon. Alloy steels contain varying amounts of carbon as well as other metals, such as chromium, vanadium, molybdenum, nickel, tungsten, etc. Their alloy content raises their cost, and so they are usually only employed for specialist uses. One common alloy steel, though, is stainless steel. Recent developments in ferrous metallurgy have produced a growing range of microalloyed steels, also termed 'HSLA' or high-strength, low alloy steels, containing tiny additions to produce high strengths and often spectacular toughness at minimal cost.

Photon mass attenuation coefficient for iron.

Apart from traditional applications, iron is also used for protection from ionizing radiation. Although it is lighter than another traditional protection material, lead, it is much stronger mechanically. The attenuation of radiation as a function of energy is shown in the graph.

The main disadvantage of iron and steel is that pure iron, and most of its alloys, suffer badly from rust if not protected in some way. Painting, galvanization, passivation, plastic coating and bluing are all used to protect iron from rust by excluding water and oxygen or bycathodic protection.
Iron compounds

Although its metallurgical role is dominant in terms of amounts, iron compounds are pervasive in industry as well being used in many niche uses. Iron catalysts are traditionally used in the Haber-Bosch Process for the production of ammonia and the Fischer-Tropsch process for conversion of carbon monoxide tohydrocarbons for fuels and lubricants.[61] Powdered iron in an acidic solvent was used in the Bechamp reduction the reduction ofnitrobenzene to aniline.[62]

Iron(III) chloride finds use in water purification and sewage treatment, in the dyeing of cloth, as a coloring agent in paints, as an additive in animal feed, and as an etchant for copper in the manufacture of printed circuit boards.[63] It can also be dissolved in alcohol to form tincture of iron. The other halides tend to be limited to laboratory uses.

Iron(II) sulfate is used as a precursor to other iron compounds. It is also used to reduce chromate in cement. It is used to fortify foods and treat iron deficiency anemia. These are its main uses. Iron(III) sulfate is used in settling minute sewage particles in tank water.Iron(II) chloride is used as a reducing flocculating agent, in the formation of iron complexes and magnetic iron oxides, and as a reducing agent in organic synthesis.
Biological role

Iron is abundant in biology.[64] Iron-proteins are found in all living organisms, ranging from the evolutionarily primitive archaea to humans. The color of blood is due to the hemoglobin, an iron-containing protein. As illustrated by hemoglobin, iron is often bound to cofactors, e.g. in hemes. The iron-sulfur clusters are pervasive and include nitrogenase, the enzymes responsible for biological nitrogen fixation. Influential theories of evolution have invoked a role for iron sulfides in the iron-sulfur world theory.

Structure of Heme b, in the protein additional ligand(s) would be attached to Fe.

Iron is a necessary trace element found in nearly all living organisms. Iron-containing enzymes and proteins, often containing heme prosthetic groups, participate in many biological oxidations and in transport. Examples of proteins found in higher organisms include hemoglobin, cytochrome (see high-valent iron), and catalase.[65]
Bioinorganic compounds

The most commonly known and studied "bioinorganic" compounds of iron (i.e., iron compounds used in biology) are the heme proteins: examples are hemoglobin, myoglobin, and cytochrome P450. These compounds can transport gases, build enzymes, and be used in transferring electrons. Metalloproteins are a group of proteins with metal ion cofactors. Some examples of iron metalloproteins are ferritin and rubredoxin. Many enzymes vital to life contain iron, such as catalase, lipoxygenases, and IRE-BP.
Health and diet
Main articles: Iron deficiency (medicine) and Human iron metabolism

Iron is pervasive, but particularly rich sources of dietary iron include red meat, lentils, beans,poultry, fish, leaf vegetables, watercress, tofu, chickpeas, black-eyed peas, blackstrap molasses, fortified bread, and fortified breakfast cereals. Iron in low amounts is found in molasses, teff and farina. Iron in meat (heme iron) is more easily absorbed than iron in vegetables.[66] Although some studies suggest that heme/hemoglobin from red meat has effects which may increase the likelihood ofcolorectal cancer,[67][68] there is still some controversy,[69] and even a few studies suggesting that there is not enough evidence to support such claims.[70]

Iron provided by dietary supplements is often found as iron(II) fumarate, although iron sulfate is cheaper and is absorbed equally well. Elemental iron, or reduced iron, despite being absorbed at only one third to two thirds the efficiency (relative to iron sulfate),[71] is often added to foods such as breakfast cereals or enriched wheat flour. Iron is most available to the body when chelated to amino acids[72]and is also available for use as a common iron supplement. Often the amino acid chosen for this purpose is the cheapest and most common amino acid, glycine, leading to "iron glycinate" supplements.[73] The Recommended Dietary Allowance (RDA) for iron varies considerably based on age, gender, and source of dietary iron (heme-based iron has higher bioavailability).[74] Infants may require iron supplements if they are bottle-fed cow's milk.[75] Blood donors and pregnant women are at special risk of low iron levels and are often advised to supplement their iron intake.[76]
Uptake and storage

Iron acquisition poses a problem for aerobic organisms, because ferric iron is poorly soluble near neutral pH. Thus, bacteria have evolved high-affinity sequestering agents called siderophores.[77][78][79]

After uptake, in cells, iron storage is carefully regulated; "free" iron ions do not exist as such. A major component of this regulation is the protein transferrin, which binds iron ions absorbed from the duodenum and carries it in the blood to cells.[80] In animals, plants, and fungi, iron is often the metal ion incorporated into the heme complex. Heme is an essential component of cytochrome proteins, which mediate redox reactions, and of oxygen carrier proteins such as hemoglobin, myoglobin, and leghemoglobin.

Inorganic iron contributes to redox reactions in the iron-sulfur clusters of many enzymes, such as nitrogenase (involved in the synthesis of ammonia from nitrogen and hydrogen) and hydrogenase. Non-heme iron proteins include the enzymes methane monooxygenase(oxidizes methane to methanol), ribonucleotide reductase (reduces ribose to deoxyribose; DNA biosynthesis), hemerythrins (oxygentransport and fixation in marine invertebrates) and purple acid phosphatase (hydrolysis of phosphate esters).

Iron distribution is heavily regulated in mammals, partly because iron ions have a high potential for biological toxicity.[81]
Regulation of uptake
Main article: Hepcidin

Iron uptake is tightly regulated by the human body, which has no regulated physiological means of excreting iron. Only small amounts of iron are lost daily due to mucosal and skin epithelial cell sloughing, so control of iron levels is mostly by regulating uptake.[82]Regulation of iron uptake is impaired in some people as a result of a genetic defect that maps to the HLA-H gene region on chromosome 6. In these people, excessive iron intake can result in iron overload disorders, such as hemochromatosis. Many people have a genetic susceptibility to iron overload without realizing it or being aware of a family history of the problem. For this reason, it is advised that people do not take iron supplements unless they suffer from iron deficiency and have consulted a doctor. Hemochromatosisis estimated to cause disease in between 0.3 and 0.8% of Caucasians.[83]

MRI finds that iron accumulates in the hippocampus of the brains of those with Alzheimer's disease and in the substantia nigra of those with Parkinson disease.[84]
Permeable reactive barriers

Zero-valent iron is the main reactive material for permeable reactive barriers.[85]
Precautions

NFPA 704


1
0
1

Fire diamond for powdered iron metal

Main article: Iron poisoning

Large amounts of ingested iron can cause excessive levels of iron in the blood. High blood levels of free ferrous iron react with peroxides to produce free radicals, which are highly reactive and can damage DNA, proteins, lipids, and other cellular components. Thus, iron toxicity occurs when there is free iron in the cell, which generally occurs when iron levels exceed the capacity of transferrin to bind the iron. Damage to the cells of the gastrointestinal tract can also prevent them from regulating iron absorption leading to further increases in blood levels. Iron typically damages cells in the heart, liver and elsewhere, which can cause significant adverse effects, including coma, metabolic acidosis, shock, liver failure, coagulopathy, adult respiratory distress syndrome, long-term organ damage, and even death.[86] Humans experience iron toxicity above 20 milligrams of iron for every kilogram of mass, and 60 milligrams per kilogram is considered a lethal dose.[87] Overconsumption of iron, often the result of children eating large quantities of ferrous sulfate tablets intended for adult consumption, is one of the most common toxicological causes of death in children under six.[87] The Dietary Reference Intake (DRI) lists the Tolerable Upper Intake Level (UL) for adults as 45 mg/day. For children under fourteen years old the UL is 40 mg/day.

The medical management of iron toxicity is complicated, and can include use of a specific chelating agent called deferoxamine to bind and expel excess iron from the body.

Read More
